容積流量：19.06~32m3/min
排氣壓力：50~150kpa
啟動方式：工頻或變頻
性能特點:
1、含油量0級的高標準無油壓縮空氣；
2、壓縮過程沒有潤滑油參與，確保壓縮空氣不含潤滑油；
3、特殊的密封件設計，完全隔絕潤滑油進入壓縮腔；
4、電機變頻控制，智能匹配轉速，保證穩定的排氣壓力；
5、電機采用工頻或永磁變頻控制，提高節能效果；
6、性能范圍：介質：空氣、氮?dú)?、工藝氣等；啟動方式：工頻或變頻；流量：3~100m3/min；升壓：30~150kpa；
| 主機型號 | 電機轉速 | 氣量 | 軸功率 | 氣量 | 軸功率 | 氣量 | 軸功率 | 氣量 | 軸功率 | 氣量 | 軸功率 | 氣量 | 軸功率 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| (m3/h) | (kW) | (m3/h) | (kW) | (m3/h) | (kW) | (m3/h) | (kW) | (m3/h) | (kW) | (m3/h) | (kW) | ||
| 排氣壓力 | 40Kpa | 50Kpa | 60Kpa | 70Kpa | 80Kpa | 90Kpa | |||||||
| HDLG204 | 2500 | 1247.7 | 22.3 | 1238.2 | 25.2 | 1228.8 | 28.5 | 1219.3 | 31.0 | 1209.8 | 33.2 | 1200.4 | 35.9 |
| 2600 | 1320.0 | 23.0 | 1310.0 | 26.0 | 1300.0 | 29.4 | 1290.0 | 32.0 | 1280.0 | 34.3 | 1270.0 | 37.0 | |
| 2700 | 1377.6 | 23.9 | 1367.2 | 27.0 | 1356.8 | 30.5 | 1346.3 | 33.2 | 1335.9 | 35.6 | 1325.4 | 38.4 | |
| 2800 | 1435.8 | 24.8 | 1424.9 | 28.0 | 1414.0 | 31.7 | 1403.2 | 34.5 | 1392.3 | 36.9 | 1381.4 | 39.8 | |
| 2900 | 1494.5 | 25.7 | 1483.2 | 29.0 | 1471.9 | 32.8 | 1460.5 | 35.7 | 1449.2 | 38.3 | 1437.9 | 41.3 | |
| 3000 | 1553.8 | 26.5 | 1542.0 | 30.0 | 1530.2 | 33.9 | 1518.5 | 36.9 | 1506.7 | 39.6 | 1494.9 | 42.7 | |
| 3100 | 1613.6 | 27.4 | 1601.4 | 31.0 | 1589.1 | 35.1 | 1576.9 | 38.2 | 1564.7 | 40.9 | 1552.5 | 44.1 | |
| 3200 | 1674.0 | 28.3 | 1661.3 | 32.0 | 1648.6 | 36.2 | 1635.9 | 39.4 | 1623.2 | 42.2 | 1610.6 | 45.5 | |
| 3300 | 1734.9 | 29.2 | 1721.8 | 33.0 | 1708.6 | 37.3 | 1695.5 | 40.6 | 1682.3 | 43.5 | 1669.2 | 47.0 | |
| 3400 | 1796.4 | 30.1 | 1782.8 | 34.0 | 1769.2 | 38.4 | 1755.6 | 41.8 | 1742.0 | 44.9 | 1728.4 | 48.4 | |
| 3500 | 1858.5 | 31.0 | 1844.4 | 35.0 | 1830.3 | 39.6 | 1816.3 | 43.1 | 1802.2 | 46.2 | 1788.1 | 49.8 | |
| 3600 | 1921.2 | 31.8 | 1906.6 | 36.0 | 1892.1 | 40.7 | 1877.5 | 44.3 | 1862.9 | 47.5 | 1848.4 | 51.2 | |
| 排氣壓力 | 100Kpa | 110Kpa | 120Kpa | 130Kpa | 140Kpa | 150Kpa | |||||||
| HDLG204 | 2500 | 1190.9 | 38.8 | 1181.5 | 41.7 | 1172.0 | 44.6 | 1162.6 | 47.5 | 1153.1 | 50.4 | 1143.7 | 53.3 |
| 2600 | 1260.0 | 40.0 | 1250.0 | 43.0 | 1240.0 | 46.0 | 1230.0 | 49.0 | 1220.0 | 52.0 | 1210.0 | 55.0 | |
| 2700 | 1315.0 | 41.5 | 1304.6 | 44.7 | 1294.1 | 47.8 | 1283.7 | 50.9 | 1273.3 | 54.0 | 1262.8 | 57.1 | |
| 2800 | 1370.5 | 43.1 | 1359.6 | 46.3 | 1348.8 | 49.5 | 1337.9 | 52.8 | 1327.0 | 56.0 | 1316.1 | 59.2 | |
| 2900 | 1426.6 | 44.6 | 1415.2 | 48.0 | 1403.9 | 51.3 | 1392.6 | 54.7 | 1381.3 | 58.0 | 1370.0 | 61.3 | |
| 3000 | 1483.1 | 46.2 | 1471.4 | 49.6 | 1459.6 | 53.1 | 1447.8 | 56.5 | 1436.1 | 60.0 | 1424.3 | 63.5 | |
| 3100 | 1540.2 | 47.7 | 1528.0 | 51.3 | 1515.8 | 54.8 | 1503.6 | 58.4 | 1491.3 | 62.0 | 1479.1 | 65.6 | |
| 3200 | 1597.9 | 49.2 | 1585.2 | 52.9 | 1572.5 | 56.6 | 1559.8 | 60.3 | 1547.2 | 64.0 | 1534.5 | 67.7 | |
| 3300 | 1656.1 | 50.8 | 1642.9 | 54.6 | 1629.8 | 58.4 | 1616.6 | 62.2 | 1603.5 | 66.0 | 1590.3 | 69.8 | |
| 3400 | 1714.8 | 52.3 | 1701.2 | 56.2 | 1687.5 | 60.2 | 1673.9 | 64.1 | 1660.3 | 68.0 | 1646.7 | 71.9 | |
| 3500 | 1774.0 | 53.8 | 1759.9 | 57.9 | 1745.9 | 61.9 | 1731.8 | 66.0 | 1717.7 | 70.0 | 1703.6 | 74.0 | |
| 3600 | 1833.8 | 55.4 | 1819.3 | 59.5 | 1804.7 | 63.7 | 1790.2 | 67.8 | 1775.6 | 72.0 | 1761.1 | 76.2 | |
